Quectel Expands Automotive-Grade IMU Portfolio with Three New 6-Axis Modules

Quectel Wireless Solutions announced in Munich, Germany, an expansion of its automotive-grade inertial measurement unit (IMU) portfolio. This expansion introduces three new 6-axis modules: the LUA501RA, LUA300C, and LUA301C. These modules are engineered to deliver precise motion, tilt, and orientation sensing, distinguished by automotive-grade reliability and factory calibration, which ensures a level of precision surpassing that of consumer-grade sensors.

The LUA501RA stands as the flagship module in this new release. It is a compact, high-performance 6-axis IMU developed in accordance with ISO 26262 and built around Bosch’s SMI270 chip. This module integrates a 3-axis gyroscope and a 3-axis accelerometer, making it suitable for functional-safety-critical motion-sensing applications, including those beyond the automotive sector.

Accompanying the LUA501RA, Quectel also unveiled the LUA300C and LUA301C. These are compact, automotive-grade, factory-calibrated 6-axis IMU modules based on ST’s ASM330LHB chip. While both modules share the same electrical performance and calibration methodology, they offer distinct mechanical mounting options: the LUA300C utilises pin-mounting, and the LUA301C employs screw-mounting, differing in size and weight accordingly.

Collectively, these three modules provide a diverse range of sensor platforms, footprints, and mechanical mounting options, including an ASIL-B development pedigree option. Quectel emphasizes that this expanded portfolio is designed to meet specific program, footprint, and functional-safety requirements with production-ready modules, thereby simplifying design complexity often associated with discrete sensor implementations.

Specifications

Key Features

• Quectel's portfolio expands with three new 6-axis automotive-grade IMU modules: LUA501RA, LUA300C, and LUA301C.
• The LUA501RA integrates a 3-axis gyroscope and 3-axis accelerometer, built around Bosch’s SMI270 chip.
• The LUA501RA was developed in accordance with ISO 26262, supporting functional-safety-critical applications.
• The LUA501RA is individually factory-calibrated for precision, including temperature-dependent bias compensation across -40°C to +105°C.
• The LUA300C and LUA301C are compact, automotive-grade 6-axis IMU modules based on ST’s ASM330LHB chip.
• Both LUA300C and LUA301C feature precision-trimmed and factory-calibrated gyroscope and accelerometer parameters.
• The LUA300C offers pin-mounting (18.8 × 10.4 × 11.1 mm, ~2.4 g), while the LUA301C provides screw-mounting (19.5 × 11.5 × 12.0 mm, ~8 g).
• The LUA501RA measures 11.5 mm × 19.5 mm × 12.0 mm and weighs approximately 8.0 g.
• The portfolio offers different sensor platforms, footprints, and mechanical mounting options, including an ASIL-B development pedigree option.
• These production-ready modules aim to reduce the complexity associated with discrete sensor designs.

Applications

• Automotive ADAS systems
• Automotive ADCU systems
• Machine control and industrial automation
• High-precision GNSS/INS navigation
• Autonomous mobile robots
• Unmanned vehicles
• Industrial robotics
• Automated excavator-arm control

Availability

Quectel’s new automotive-grade 6-axis IMU modules are available as the LUA300C and LUA501RA. Both modules integrate a 3-axis accelerometer and 3-axis gyroscope in compact automotive-grade designs, providing factory-calibrated IMU solutions for automotive and industrial applications. The LUA300C (00) measures 18.8 mm × 10.4 mm × 11.1 mm and operates from -40 °C to +105 °C, while the LUA501RA (00) measures 11.5 mm × 19.5 mm × 12.0 mm and has an operating temperature range of -40 °C to +105 °C.
